Original Rosemount 214C temperature sensor, PT100 RTD & K/J/T thermocouple, -196~1200℃, Class A accuracy, explosion-proof certification, match 644/3144/648 transmitter, stock available.
1. Product Overview
Rosemount 214C is a mainstream industrial temperature probe from Emerson, divided into RTD PT100 and Thermocouple two series, widely used for precise process temperature measurement in chemical, oil & gas, power, food industries.
Core keywords: Rosemount 214C, 214C RTD sensor, 214C thermocouple, PT100 temperature probe, industrial temperature sensor.
2. Core Advantages
1. Dual element optional: Single/dual PT100, thin-film anti-vibration / wire-wound high precision
2. Wide temperature range: RTD -196~600℃; TC K/J/T -196~1200℃
3. High accuracy: Class A/B RTD, support Callendar-Van Dusen matching with transmitters
4. Strong shock resistance: Pass IEC high vibration test, stable for pipeline & tank measurement
5. Complete certification: Ex, FM, SIL optional for hazardous area
6. Flexible installation: Spring loaded fitting, customizable insertion length & sheath material
7. Full matching: Compatible with Rosemount 644, 3144, 648 wireless transmitter, 114C thermowell
3. Main Technical Specs
• Sensor Type: PT100 RTD / Type K, J, T Thermocouple
• Temperature Range: RTD -196 ~ 600°C; TC -196 ~ 1200°C
• Accuracy: Class A / Class B RTD
• Sheath Standard: 1/4" mineral insulated MI cable
• Vibration Grade: Up to 10g for severe vibration working condition
• Protection: IP65, global hazardous location approvals
• Matching Transmitter: 644 wired, 3144 HART, 648 wireless temperature transmitter
4. Application Industries
Oil & gas refinery, chemical plant, power plant, pharmaceutical, food beverage, water treatment, storage tank temperature monitoring
5. Matching Complete Solution
214C Sensor + 114C Thermowell + 644/3144/648 Transmitter, one-stop temperature measuring point assembly, factory pre-assembly available
6. FAQ
Q1: What's the difference between 214C RTD and thermocouple model?
A: RTD 214C for low & medium temperature (-196~600℃), higher precision; Thermocouple 214C for high temperature up to 1200℃.
Q2: Can 214C work with wireless transmitter?
A: Yes, perfectly matched with Rosemount 648 wireless temperature transmitter.
Q3: Are your 214C original genuine?
A: All Rosemount 214C are original factory new, complete calibration certificate, no clone/refurbished stock.
Q4: Can customize probe length and thread?
A: Support customized insertion length, NPT/BSP thread, sheath material, explosion-proof head options.
Call To Action
Send your model code, temperature range and working condition to get quotation & datasheet, sufficient stock for fast delivery.
