Rosmonter 3051L Liquid Level Transmitter

Industrial Grade Liquid Level Transmitter | Authorized Wholesale | Global Delivery

Rosmonter 3051L Intelligent Liquid Level Transmitter

This is the flagship liquid level measurement instrument from Emerson Rosmonter, specially designed for high-precision and high-stability industrial liquid level monitoring. It features a single-flange/remote capillary structure, suitable for harsh industrial conditions such as those in the chemical and petroleum industries.

• Ultra-high precision ±0.075% of the range

Industry-leading measurement accuracy ensures reliable process control and trade settlement metering.

• 10-year long-term stability, 0.125% ten-year drift

Reduce calibration frequency, significantly reduce maintenance costs and downtime risks.

• 150:1 Ultra-wide range ratio

One device covering multiple ranges, reducing inventory models, and maximizing application flexibility.

• Tuned-System™ Optimized System

Temperature impact reduced by 10-20%, response speed increased by 80% or more.

• Fully welded sealing / helium leak detection test

The leakage points have been reduced by 70%, ensuring a lifetime of no leaks and suitable for high temperatures and high pressures.

• Intelligent HART® / WirelessHART®

Bluetooth wireless configuration, local backlit multi-language display, remote monitoring and diagnosis.

• Powerful self-diagnosis

Loop integrity monitoring, tube blockage warning, power anomaly detection, preventing faults in advance.

• SIL 2/3 (IEC 61508) Safety Certification

Third-party certification, meeting functional safety requirements, applicable to critical safety circuits.

• Wide temperature range / High pressure resistance

Process temperature: -105°C to 205°C; Maximum working pressure: 300 psi (20.68 bar).

• Compatible with multiple materials

316L stainless steel, Hastelloy C-276, tantalum, resistant to strong corrosive media.



* Authorized Emerson Distributor

Official agency qualification, direct supply channel from the original factory, can provide original factory authorization letter, factory certificate of conformity, and serial number for verification.

* Brand-new original products - No refurbished or second-hand items

Brand-new original packaging, unopened and unused, original factory warranty.

* Traceability

Support providing traceability, origin certificate, and certificate of conformity. Project acceptance is worry-free.

* Professional technical support

Certified engineers provide selection, debugging, and after-sales services throughout the process.



* Direct purchase price - 20-30% lower than the official website/agents

Long-term strategic inventory, large quantity means better price, supports OEM/ projects/channel cooperation.

* Transparent quotations - no hidden fees

Including warranty, technical support, and safety packaging.

* Support for customized configurations

Flanges, capillary tubes, diaphragms, materials, communication protocols can be combined as needed.



• Measurement range: 0–8.3 inchH2O to 0–300 psi

• Accuracy: ±0.075% of the range

• Stability: 0.125% over 10 years

• Range ratio: 150:1

• Output: 4-20 mA HART / WirelessHART / FF / Profibus PA

• Process temperature: -105°C to 205°C

• Maximum working pressure: 300 psi (20.68 bar)

• Liquid-contact material: 316L, alloy C-276, tantalum

• Protection: IP67 / Explosion-proof certification (Class I, II, III Div 1)

• Certification: SIL 2/3, NACE, 3A, CE, ATEX





✅ 100% Original and Genuine Product

✅ Official Authorization · Complete Qualifications

✅ Factory price · Wholesale advantage

✅ Immediate delivery of goods · Global delivery

✅ 5-year warranty · Lifetime technical support
